SC-0895AU-4G with 4G LTE 4, 8 SIM supports TDD, FDD, VoLTE

SC-0895AU-4G with 4G LTE 4, 8 SIM supports TDD, FDD, VoLTE

The SC-0895AU-4G is a 4G LTE gateway with support for 4 or 8 SIM cards, offering seamless connectivity across TDD and FDD LTE networks. It supports VoLTE, ensuring high-quality voice calls over LTE. Ideal for businesses requiring reliable multi-SIM communication, it provides enhanced network redundancy and performance

            KEY FEATURES:

1. 4 or 8 LTE Channels on Demands
2. Supports to work with different mobile networks:
3. Compatible with LTE-FDD/LTE-TDD/WCDMA/GSM Networks
4. Supports Make Call through VoLTE
5. HTTP API for SMS Application Integration
6. SMS to Email and Email to SMS
7. Flexible Dial Rules and Manipulation Rules

VOICE PROCESSING:

1. Protocol: SIP v2.0, RFC3261, SIP TLS
2. Codecs: G.711A/U law, G.723.1, G.729A/B
3. Silence Suppression
4. Comfort Noise Generator (CNG)
5. Voice Activity Detection (VAD)
6. Echo Cancellation: G.168 with up to 128ms
7. Dynamic Jitter Buffer
8. DTMF: RFC2833, SIP Info
9. Call Progress Tone Generation
10. Programmable Gain Control
11. NAT: STUN, Dynamic NAT, Static NAT

SOFTWARE FEATURES:

1. Calling Type: Mobile to VoIP, VoIP to Mobile
2. SIP Trunk and Trunk Group
3. Caller/Called Number Manipulation Rules
4. SIP Codes Mapping
5. White/Black List
6. PSTN Hotline
7. VoIP Hotline
8. Abnormal Call Monitor
9. Call Minutes Limitation for Ports/Single Call
10. Balance Check
11. Low Balance Alarm
12. Auto Update SIM Number
13. Random Call Interval
14. Auto CLIP
15. Signaling & RTP Encryption
16. SMPP for SMS

FREQUENCY BANDS:

Type AU.  FDD: B1/B2/B3/B4/B5/B7/B8/B28

                   TDD: B40

          WCDMA: B1(2100MHz)/B2/B5/B8(900MHz)

GSM:B2/B3/B5/B8

* SC-0895-4G supports different frequency bands, please choose a dedicated type based on the region or operator.

MOBILE:

1. USSD Encoding: Unicode/ASCII
2. CNAM Caller ID
3. HTTP API for SMS
4. Polarity Reversal
5. PIN Modify
6. CID/CLIR
7. SMS Send and Receive
8. SMS to Email
9. Call Waiting/Call Back
10. Call Forward
11. GSM Audio Coding: HR, FR, EFR, AMR_FR, AMR_HR

NETWORK:

1. Static IP, DHCP Client, PPPoE
2. Network Protocols:
3. TCP/UDP, TFTP, FTP, RTP/ RTCP, SSH, ARP, RARP, ICMP Ping, NTP, HTTP, DNS
4. Static/Dynamic ARP Request
5. PPTP VPN

PHYSICAL INTERFACE:

1. Mobile: 4/8 Channels
2. Antennas Connectors: SMA
3. Ethernet Interfaces: 2 x 10/100 Base-T, RJ45
4. LED Indicators: Power, RUN, Signal Strength Indicators
5. Console: 1 x RS232 115200bps

MAINTENANCE:

1. SSH
2. Web/Telnet Configuration
3. Configure Backup/Restore
4. Firmware Upgrade by HTTP/TFTP
5. Factory Reset
6. CDR (10000 Lines CDRs Storage Locally)
7. Syslog/ Filelog
8. Ping and Tracert
9. Traffic statistics: TCP, UDP, RTP
10. VoIP Call Statistics
11. PSTN Call statistics: ASR, ACD, PDD
12. Voice Diagnose with Loopback
13. GSM Network Test
14. IVR Customization
15. Auto Provisioning
16. SIP/RTP/PCM Capture
